MOTION-CONNECT cables for SINUMERIK 808D ADVANCED

• Заказные данные
  (14)
• Информационные материалы

  Конфигурация



  Connection overview for SINUMERIK 808D ADVANCED T/SINUMERIK 808D ADVANCED M PPU 161.3/PPU 160.3

  Representation in connection overviews

  Symbol	Explanation
  	Connector with pin contacts
  	Connector with socket contacts
  	Exposed core ends
  	Cable is not included in the scope of delivery. It must be provided by the customer.





  Технические данные

  Aeticle No.	6FC5548-0BA20-….	6FC5548-0BA05-….
  Product name	Drive bus cable PPU 16x.3 – SINAMICS V70 SINAMICS V70 – SINAMICS V70	Setpoint cable PPU 16x.3 - spindle drive
  No. of cores	2	4
  Certificate of suitability
  cURus or UR/CSA1)	UL1581	UL2576
  RoHS conformity	Yes	Yes
  Operating voltage	100 V	30 V
  Test voltage, rms	3600 V	500 V
  Operating temperature on the surface
  Fixed installation	-40 … +80 °C	-20 … +80 °C
  Flexible installation	-40 … +60 °C	0 … 60 °C
  Smallest bending radius
  Fixed installation	75 mm	60 mm
  Flexible installation	150 mm	120 mm
  Insulation material, incl. jacket	PVC	PVC
  Oil resistance	Limited mineral oil and fats resistance	70 °C × 4 h
  Outer jacket	PVC Gray	PVC Gray
  Flame-retardant	IEC 60332–3–24	VW-1





  ¹⁾ The respective registration number is printed on the cable jacket.



  Article No.	6FX8002-2CD01-....	6FX8002-2BB01-....
  Product name	Signal cable PPU 16x.3 - Incremental encoder for spindle (TTL)	Signal cable PPU 16x.3 - handwheel
  Certificate of suitability
  cURus or UR/CSA1)	UL758-CSA-C22.2-N.210.2-M90	UL758-CSA-C22.2-N.210.2-M90
  RoHS conformity	Yes	Yes
  Rated voltage	30 V	30 V
  Test voltage, rms	500 V	500 V
  Operating temperature on the surface
  Fixed installation	-50 … +80 °C	-50 … +80 °C
  Flexible installation	-20 … +60 °C	-20 … +60 °C
  Tensile stress, max.
  Fixed installation	50 N/mm2	50 N/mm2
  Flexible installation	20 N/mm2	20 N/mm2
  Smallest bending radius
  Fixed installation	35 mm	35 mm
  Flexible installation	70 mm	70 mm
  Torsional stress	Absolute 30°/m	Absolute 30°/m
  Bending	10 million	10 million
  Traversing velocity	300 m/min	300 m/min
  Acceleration	5 m/s2	5 m/s2
  Insulation material, incl. Jacket	CFC/silicone-free IEC 60754‑1/DIN VDE 0472-815	CFC/silicone-free IEC 60754‑1/DIN VDE 0472-815
  Oil resistance	EN 60811-2-1	EN 60811-2-1
  Outer jacket	PVC DESINA color green RAL 6018	PVC DESINA color green RAL 6018
  Flame-retardant	EN 60332-1-1 to 1-3	EN 60332-1-1 to 1-3





  ¹⁾ The respective registration number is printed on the cable jacket.

  For general information about MOTION-CONNECT please refer to Introduction.
